TITAN V

Key Metrics

Save this GPU, then open another GPU page to compare them side by side.

Identity
Entry Type	Reference GPU
Official Name	NVIDIA TITAN V
GPU Codename	GV100
Architecture	Volta
Launch Date	2017-12-07
Market Segment Notes	Desktop, Flagship in NVIDIA TITAN Series
Core Specs
GPU Die	GV100
Process Node	TSMC 12 nm
Transistor Count	21.1 billion
Die Size	815 mm²
CUDA Cores	5120
SM Count	80
TMUs	320
ROPs	96
AI Units / Tensor Cores	640
Base Clock	1,200 MHz
Boost Clock	1,455 MHz
Pixel Fillrate	139.7 GP/s
Texture Fillrate	465.6 GT/s
FP32 Throughput	14.9 TFLOPS
FP16 Throughput	29.8 TFLOPS
FP64 Throughput	7.45 TFLOPS
Memory
Memory Size	12 GB
Memory Type	HBM2
Memory Bus Width	3,072-bit
Memory Clock	848 MHz
Memory Bandwidth	651.3 GB/s
L2 Cache	4 MB
L1 Cache	96 KB
Board and Display
TDP / TBP	250 W
Recommended PSU	600 W
Power Connectors	1x 6-pin + 1x 8-pin
Interface	PCIe 3.0 x16
Display Outputs	1x HDMI 2.0, 3x DisplayPort 1.4a
Slot Width	Dual-slot, 267 mm length, 40 mm width
Card Length	267 mm
Board Partner Model	Reference or OEM specification
Reference Design	NVIDIA reference design
Software
CUDA Compute Capability	7.0
Shader Model	6.8
DirectX Support	DirectX 12.1
Vulkan Support	Vulkan 1.4
OpenGL Support	OpenGL 4.6
OpenCL Support	OpenCL 3.0
